商品の詳細:
|
| Model: | C9500-16X-E | Switching capacity: | Up to 480 Gbps |
|---|---|---|---|
| Forwarding rate: | Up to 360 Mpps | DRAM: | 16 GB |
| Flash: | 16 GB | Power Supply Selection: | PWR-C4-950WAC-R or PWR-C4-950WDC-R |
| Dimensions: | 1.73 x 17.5 x 21.52 in | Condition: | Original new |
| Warranty: | 1 year | ||
| ハイライト: | Cisco Catalyst 16-port 10G switch,C9500-16X-E network switch,Cisco Ethernet switch NW Essentials |
||
| Attribute | Value |
|---|---|
| Model | C9500-16X-E |
| Switching capacity | Up to 480 Gbps |
| Forwarding rate | Up to 360 Mpps |
| DRAM | 16 GB |
| Flash | 16 GB |
| Power Supply Selection | PWR-C4-950WAC-R or PWR-C4-950WDC-R |
| Dimensions | 1.73 x 17.5 x 21.52 in |
| Condition | Original new |
| Warranty | 1 year |
The C9500-16X-E is a Cisco Catalyst 9500 16-port 10G switch with Network Essentials License. The Cisco Catalyst 9500 Series Switches represent the next generation of enterprise-class core and aggregation layer switches, featuring full programmability and serviceability.
Built on an x86 CPU architecture, the Catalyst 9500 Series is Cisco's premier purpose-built fixed core and aggregation enterprise switching platform, specifically designed for security, IoT, and cloud applications. This series marks the industry's first purpose-built 40 Gigabit Ethernet line of switches targeted for enterprise campus environments.
| Feature | C9500-16X-E | C9500-32C-A |
|---|---|---|
| Description | Cisco Catalyst 9500 16-port 10G switch, NW Ess. License | Cisco Catalyst 9500 Series high performance 32-port 100G switch, NW Adv. License |
| Switching capacity | Up to 480 Gbps | Up to 6.4 Tbps |
| Forwarding rate | Up to 360 Mpps | Up to 2 Bpps |
| DRAM | 16 GB | 16 GB |
| Flash | 16 GB | 16 GB |
| Dimensions (H x W x D) | 1.73 x 17.5 x 21.52 in | 1.73 x 17.5 x 21.2 in |
| Rack units (RU) | 1 RU | 1RU |
| Performance Specifications | |
| Switching capacity | Up to 480 Gbps |
| Forwarding rate | Up to 360 Mpps |
| Total number of MAC addresses | Up to 64,000 |
| Total number of IPv4 routes (ARP plus learned routes) | Up to 64,000 indirect / Up to 80,000 host |
| Total number of IPv6 routes | Up to 32,000 indirect / Up to 40,000 host |
| QoS ACL scale | Up to 18,000 |
| Security ACL scale | Up to 18,000 |
| FNF entries | Up to 512,000 |
| DRAM | 16 GB |
| Flash | 16 GB |
| VLAN IDs | 4,000 |
| Total Switched Virtual Interfaces (SVIs) | 4,000 |
| Jumbo frame | 9,198 bytes |
| Power Supply Specifications | |
| Power Supply Selection | PWR-C4-950WAC-R or PWR-C4-950WDC-R |
| Power max rating | 950 W |
| Physical Specifications | |
| Dimensions (H x W x D) | 1.73 x 17.5 x 21.52 in |
| Rack units (RU) | 1 RU |
| Input voltage | 90 to 264 VAC |
| Operating temperature | 32° to 104°F (0° to 40°C) |
| Storage temperature | -4° to 149°F (-20° to 65°C) |
| Relative humidity operating and nonoperating noncondensing | Ambient (noncondensing) operating: 5% to 90% Ambient (noncondensing) nonoperating and storage: 5% to 95% |
| Altitude | Operation up to 6000 feet at 55°C and 13,000 feet at 45°C |
| MTBF (hours) | 315,790 |
