商品の詳細:
|
| ブランド: | ZTE | モデル: | 8862 AS2100 |
|---|---|---|---|
| タイプ: | RRU | 使用法: | ベースステーション |
| 状態: | 使用済み | 保証: | 3ヶ月 |
| リードタイム: | 1〜3日 | 受渡し時間: | 3〜5日 |
Overview
Here is a collection of specifications derived from the sources:
| Parameter | Value / Range |
|---|---|
| Supported bandwidths (LTE) | 1.4, 3, 5, 10, 15, 20 MHz |
| Operating frequency bands | 850 MHz, 1800 MHz, 2100 MHz, 2600 MHz (some models) |
| Transmit / Receive configuration | 2T4R (2 transmit, 4 receive) |
| Maximum transmit power | 2 × 60 W (i.e. two transmit channels each 60 W) |
| Power supply | DC: –48 V (range: –37 V to –60 V) AC: 110/220 V (range: 90 V to 290 V) |
| Interfaces / backhaul | CPRI interface (optical SFP, LC) with rates: 1.25, 2.5, 3, 6 Gbps (CPRI v4.2) |
| Physical dimensions | ~422 × 218 × 133 mm (H × W × D) for common bands (Type I) |
| Weight | ~14 to 15 kg (without sunshield) |
| Environmental / Temperature | Operating: –40 °C to +55 °C Storage: –40 °C to +70 °C Relative Humidity: up to 100% (condensing) Protection: IP65 rating |
| Surge / Lightning protection | DC power interface: 20 kA (line-to-ground and line-to-line) Antenna interface: 10 kA line-to-ground |
| Power consumption | In GSM single mode: typical ~290 W, peak ~410 W In UMTS single mode: typical ~240 W, peak ~355 W In GSM/UMTS dual mode: typical ~330 W, peak ~410 W |
| Reliability / Availability | Availability: 99.999689% MTBF: ~322,000 hours MTTR: ~1 hour |
| Other features | - Transmit power reporting per carrier - Load protection for PA - Channel on/off switching - Software failure isolation (doesn’t affect BBU operation) |
