JL262A Aruba 2930F 48G PoE+ 4SFP Switch

JL262A
Aruba 2930F 48G PoE+ 4SFP Switch
JL262A
Aruba 2930F 48G PoE+ 4SFP Switch JL262A
Aruba 2930F 48G PoE+ 4SFP Switch JL262A
Aruba 2930F 48G PoE+ 4SFP Switch JL262A
Aruba 2930F 48G PoE+ 4SFP Switch JL262A
Aruba 2930F 48G PoE+ 4SFP Switch JL262A
Aruba 2930F 48G PoE+ 4SFP Switch JL262A
Aruba 2930F 48G PoE+ 4SFP Switch JL262A
Aruba 2930F 48G PoE+ 4SFP Switch JL262A
Aruba 2930F 48G PoE+ 4SFP Switch

大画像 :  JL262A Aruba 2930F 48G PoE+ 4SFP Switch

商品の詳細:
起源の場所: 中国
ブランド名: Aruba
証明: CE
モデル番号: JL262A
ドキュメント: LONRISE EQUIPMENT Company ...le.pdf

JL262A Aruba 2930F 48G PoE+ 4SFP Switch

説明
モデル: JL262A タイプ: Aruba 2930F 48G POE+ 4SFPスイッチ
スループット: 最大77.4 mp/s 切り替え容量: 104 GB/s
1000 MBのレイテンシ: <3.8μs(64バイトパケット) ポーパワー: 370W PoE+
寸法: 4.39 x 44.25 x 30.42cm 状態: 1年間の保証付きの真新しい

JL262A Overview


Aruba 2930F Switch Series is designed for customer creating digital workplaces optimized for mobile users with an integrated wired and wireless approach. These basic Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager and Aruba AirWave and are ideal for enterprise edge, SMB and branch offices. A powerful Aruba ProVision ASIC delivers performance and value supporting the latest SDN applications with future proof programmability. The 2930F supports 10GbE uplinks, PoE+, robust QoS, RIP routing, Access OSPF, ACLs, Tunneled Node and IPv6. This JL262A has 48 x 10/100/1000 PoE+ ports and 4 x Gigabit SFP transceiver slots for uplink connectivity. PoE+ is supported with a power budget of 370 Watts.




JL262A Specification

Model
JL262A
Brand
Aruba
Type
Aruba 2930F 48G PoE+ 4SFP Switch
I/O Ports and Slots
48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+) Duplex: 10BASE-T/100BASE-TX: half or full 1000BASE-T: full only
Additional Ports and Slots
1 dual-personality (RJ-45 or USB micro-B) serial console port
Memory and Processor
Dual Core ARM Cortex @ 1016 MHz, 1 GB DDR3 SDRAM, 12.38 MB Packet buffer size (4.5MB Ingress/7.875MB Egress), 4 GB eMMC
Management
Aruba AirWave Network Management; IMC – Intelligent Management Center, Command-line interface, Web browser, Configuration menu, SNMP manager, Telnet, RMON 1, FTP, Out-of-band management (serial RS-232C or micro USB)
1000 Mb Latency
< 3.8 μs (64-byte packets)
Throughput
Up to 77.4 Mp/s
Switching Capacity
104 Gb/s
Routing Table Size
10,000 entries (IPv4), 5,000 entries (IPv6)
MAC Address Table Size
32,768 entries
Dimensions
4.39 x 44.25 x 30.42 cm (1.73 x 17.42 x 11.98 in), 1U height
80plus.org Certification
Silver
Maximum Heat Dissipation
1652.13 kJ/hr (1566 BTU/hr)
Voltage
100 - 127 / 200 - 240 V AC, rated
Current
5.1/2.5 A
Maximum Power Rating
459 W
Idle Power
48.6 W
Frequency
50/60 Hz
PoE Power
370 W PoE+
Operating Temperature
0°C to 45°C (32°F to 113°F) up to 5,000 Feet / 0°C to 40°C (32°F to 104°F) up to 10,000 Feet
Operating Relative Humidity
15% to 95% @ 40°C (104°F) noncondensing
Nonoperating/Storage Temperature
-40°C to 70°C (-40°F to 158°F) up to 15,000 Feet
Nonoperating/Storage Relative Humidity
15% to 95% @ 65°C (149°F) noncondensing
Acoustic
Power: 55.7 dB, Pressure: 41.7 dB
Airflow Direction
Side-to-side
Safety Certifications
UL 60950-1, 2nd Edition, EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013, IEC 60950-1:2005 +A1:2009 +A2:2013, CSA 22.2 No. 60950-1-07 2nd, EN 60825-1:2007 / IEC 60825-1:2007 Class 1
Emissions
EN 55022:2010/CISPR 22 Class A, FCC CFR 47 Part 15 Class A, VCCI Class A, ICES-003 Class A, CNS 13438
Immunity
Generic: EN 55024:2010/CISPR 24, ESD IEC 61000-4-2, Radiated IEC 61000-4-3, EFT/Burst IEC 61000-4-4, Surge IEC 61000-4-5, Conducted IEC 61000-4-6, Power frequency magnetic field IEC 61000-4-8, Voltage dips and interruptions IEC 61000-4-11, Harmonics IEC/EN 61000-3-2, Flicker IEC/EN 61000-3-3
