| 製品名: | シスコスイッチ | 部品番号: | C1200-24T-4X |
|---|---|---|---|
| PoE+ポート: | 24x 10/100/1000 | 出荷: | DHL |
| 状態: | 新しい | 保証: | 1年 |
| 電力予算: | 370W | リードタイム: | 2〜3日 |
| アップリンク: | 4×10 ギガビット SFP+ |
The Cs C1200-24T-4X is an advanced networking switch designed to meet the demanding requirements of modern enterprise environments. With 24x 10/100/1000 ports, this switch ensures high-speed connectivity and reliability for extensive data resources. It is an ideal solution for businesses looking to enhance their network infrastructure with robust performance and superior quality. 110V=23.1W 220V=23.0W 110V=5.4W 220V=5.7W
C1200-24T-4X Overview
Quick Spec
Model
C1200-24T-4X
Brand
Cs
Number of Ports
24x 10/100/1000
Form Factor
1U Rackmount
Uplink Ports
4x 10G SFP+
Product Features
Product Applications
Supported Options
Accessory
Model
SFP+ Transceiver Module
SFP-10G-LR
Power Supply
PWR-C1-715WAC
Rack Mount Kit
RCKMNT-1RU
Compare to Similar Items
Model
Differences
Cs C1200-48T-4G
48x 10/100/1000 ports, 4x 1G SFP uplinks
Cs C1100-24T-2G
24x 10/100/1000 ports, 2x 1G SFP uplinks
Cs C1300-24P-4X
24x 10/100/1000 PoE+ ports, 4x 10G SFP+ uplinks
C1200-24T-4X Specification
C1200-24T-4X Specifications
Capacity in millions of packets per second (mpps) (64-byte packets)
95.23
Switching capacity in gigabits per second (Gbps)
128.0
Power dedicated to PoE
N/A
Number of ports that support PoE
N/A
System power consumption
Power consumption (with PoE)
N/A
Heat dissipation (BTU/hr)
78.8
Idle Power
Total system ports
24x Gigabit Ethernet +
4x 10 Gigabit Ethernet
RJ-45 ports
24x Gigabit Ethernet
Combo ports (RJ-45 + Small Form-Factor Pluggable [SFP])
4x SFP+
Packet buffer
1.5 MB
Unit dimensions
(W x D x H)445 x 240 x 44 mm (17.5 x 9.45 x 1.73 in)
Unit weight
2.78 kg (6.13 lb)
Fan (number)
Fanless
Acoustic noise
–
MTBF at 25°C (hours)
2,026,793
